Key Features
- Reusable cable locking mechanism
- Strong magnetic applications make it easy to attach to steel containers
and avoid vibration.
- GPS and GSM chips are embedded for location and communication
- Powered by rechargeable lithium batteries which are capable of lasting
up to 20 days.
- Material: Engineer plastic (anti-collision)
- Supports 9 alarms: steel string cut, swipe RFID tag, vibration, destroy,
wrong password, low battery with anti-false alarm algorithm.
- Device can be reused many times, can be unlocked by magnetic card on-site or unlocked remotely at center over the network
Model Number | Smart Lock KT181-SL | GPS Tracking |
|---|---|---|
Physical | L x W x D Standard Cable Length Weight Color | 195mm x 114mm x 37mm 300mm 1113 gram Black |
GSM/GPRS | Bands SIM | GSM/GPRS/EDGE Quad Band (850/900/1800/1900 MHz, LTE) Dual-SIM slots (Primary & Secondary) |
GPS | Channel
Antenna Tracking Sensitivity Location accuracy Velocity accuracy | 56 Optional Extended Ephemeris A-GPS Built-In GPS Patch Antenna -160 dBm 2,5 meter (CEP) 0.1 m/s |
Accelerometer | Type Accuracy | 3-Axis, 20 mg accuracy, up to 8g ± 2.5% |
Electrical | Battery
Active Current Drain Inactive Current Drain
Indicator | Lithium-Ion (Built-in, Rechargeable) 3.7V, 15000 mAh 240mA 0.3mA Battery capacitỵ with up to 7 days with 1 report per 0.5 minutes or 20 days with 1 report per 5 minutes 4 LED status (GPS, GSM/GPRS, Battery Charging, Low Battery), 1 piezo buzzer |
Cable | Break Load | 100kg |
COMM Port | Type | 01 Port RS232, 01 Micro USB |
Environmental | Operating Temperature Storage Temperature Humidity Weatherproofing | -20°C to +60°C -40°C to +80°C 95% non-condensing IP67 |
