FCN-P6-PRO

FCN-P6-Pro is equipped with extremely low light full-color AI imaging engine, which can achieve high-definition full- color night vision imaging beyond starlight level. It is widely used in police, night vision live broadcast and other scenarios.





Product Highlight:






Technology Highlight:



Supports both mobile and PC applications

Convolutional neural network model + massive parameter automatic learning inference
The mobile APP can connect to the FCN-P6-Pro device through WIFI, wireless control, and effectively face emergencies and harsh environments; Through the RTSP streaming application, the PC side can simultaneously play the FCN-P6-Pro shooting picture, which can be transmitted to the command and monitoring center to provide help for remote enforcement command at night.



Compatible with multiple lenses

The FCN-P6-Pro has a standard lens interface, and a wide range of lenses can be selected according to different work scenarios, ensuring that the equipmentis highly adaptable in different work scenarios

Help users get more real and comprehensive environment and target information.



Features Highlight:



FCN-P6-PRO 2



Image comparation:

FCN-P6-PRO 3

Specifications:


Image Sensor
1.69" Super starlight CMOS
Pixel size 12μm x 12μm
Maximum Resolution 2.3 MP Full-color
Video Frame Rate Adaptive frame rate or Manual selected 5fps/ 10fps/20fps/30fps MP4; H.264;
Video Recording 1920x1080 pixel resolution
Photo capture 01 photo/s; capture while video recording
Wide Dynamic120dB
Signal-to-noise Ratio > 52dB
Minimum Illumination Full-color: 0.0001Lux
ISO 2,100,000
Lens system E - mount, Interchangeable
Digital zoom 2X, 4X
HDR mode Support
Image mode AI Denoising; Detail Enhancing;
AI Defoging; AI Stabilization
Area exposure Support (by pick on the screen)
Exposure mode Auto/Manual
View Screen
5" LCD touch screen
Screen sharing Support Wired and Wireless
Storage microSD card upto 256GB
Power Supply Integrated Li-ion 7.4V DC Rechargeable
Battery or External Power
Recording time ~5 hours (with full charged battery)
Interfaces Video output: HDMI
Charging: USB Type-C; microSD card slot;
Tripod screw
Body material Alluminium
Dimensions Body: 176.5 x 100.5 x 98mm (LxDxH)
Weight850g (Body)



Accessories:



1. Standard accessories    image_2024-05-23_15-24-36-1

- Tripod
- MicroSD Card up to 256GB
- Lens mount adapter
- Rechargeable Battery
- Charger
- Transport Case
2. Option accessories
- Smart Glasses
- Rechargeable battery backup
- Cigarette charger
- IR lens fillter




3. Primes lens


FCN-P6-PRO 4

Focal length50mm
Max. Aperturef/0.95
Min. Aperturef/16





4. Telephoto lens


FCN-P6-PRO 5

Focal length70-200 mm
Focus typeManual
Zoom typeRotating
Max. Aperturef/2.8
Min. Aperturef/22

FCN-P6-PRO 6

Focal length150-600 mm
Focus typeManual
Zoom typeRotating
Max. Aperturef/5
Min. Aperturef/22

Download Catalogue
