KEY FEATURES AND BENEFITS
Handheld real time imaging system Portable Z Backscatter Transmission imaging system
Widely used in a variety of applications Safe for operators, bystanders, and the environment
The system is a compact, single-side scannerthat can be used to scan objects in hard-to-reach locations
The LS BTX120 is the world's first handheld scanner system using BACKSCATTER and TRANSMISSION imaging technology. Coming from the best proven LS series products platform, and featuring unsuppressed image performance, ergonomic user interface, advanced imaging enhancing algorithms, powerful functions and network applications, and high reliability and safety, the LS BTX120 is perfectly suitable for all applications.
Provides high resolution and real time image.
Safe for operators, bystanders, and the environment.
The system's X-ray dose complies with the ANSI radiation safety standards.
Integrated design, simple operation and maintenance.
Superior inspection capability
Effective detection of weapons, IEDs, arcotics, detectaphones and other contrabands behind metal surfaces
Simultaneous display of images of the two technologies
| |
Scan speed | 150 mm/s |
Scan time (max) | 25 s |
Generator voltage | 120 KV |
Detection capability | IEDs, narcotics, liquids and other light or organic materials. |
Imaging Processing System |
|
Image acquisition mode | Real time |
Steel penetration Bx technology | 3.5 mm steel standard |
Steel penetration Tx technology | 10 mm steel standard |
Image processing functions | Contrast, brightness, enhancement |
Screen display | 6.5 inch |
Storage | 128 Gb |
Operating system | Android |
Dimensions |
|
Scan dimensions | 235 mm (D) × 248 mm (W) × 168 mm (H) |
Panel dimensions | 720 mm (D) × 510 mm (W) × 30 mm (H) |
Scan weight | 4.2 kg |
Panel weight | 6.5 kg |
Power Supply |
|
Battery | 50 Wh |
Power consumption | 30 W |
Battery charger | 100 240 VAC, 50 / 60 Hz ～ |
Operating time | More than 3 hrs (25% duty cycle) |
Environmental Specication |
|
Operating temperature | - 20 + 50 ℃ ～ ℃ |
Storage temperature | 25 + 60 ℃ ～ ℃ |
Operating humidity | 0% ~ 93% (non-condensing) |
